Fluentd usage example with bash and ruby

Fluentd is an open source tool to collect events and logs. Its architecture allows to easily collect logs from different input sources and redirect them to different output sinks. Some input examples are HTTP, syslog, or apache logs, and some output sinks are files, mail, and databases (both RDBMS and NoSQL ones). Also, it allows to parse logs and to extract only the significative parts from each of them; saving this structured information on a DB allows much easier log searching and analysis.

The fluentd architecture can be extended with ruby plugins to support input sources and output destinations; for the scope of this example, we will use:

• MongoDB plugin for Fluent event collector;
• fluent-logger rubygem;
• the built-in tcp input and stdout output.

Installing fluentd server

The first thing to do is installing the fluentd server. You can easily do this via rubygems (beware it requires at least ruby 1.9.2):

$ gem install fluentd

When you’re done you can create a setup file:

$ fluentd -s ~/.fluentd

This will create the file ~/.fluentd/fluent.conf and setup the ~/.fluent/plugins folder.

The fluentd.conf file

Edit the configuration file with your favourite editor (which is vim, of course), and make it look like this:

## built-in TCP input
## $ echo <json> | fluent-cat <tag>
<source>
  type forward
  port 24224
</source>

## match tag=fluentd.test.** and dump to console
<match fluentd.test.**>
  type stdout
</match>

<match mongo.**>
  type mongo
  host 127.0.0.1
  port 27017
  database fluentd
  collection test

  # for capped collection
  capped
  capped_size 1024m

  # flush
  flush_interval 1s
</match>

You can see it’s made of three parts:

1. The first one is the default HTTP source input. It listens for JSON messages on port 24224.
2. The second one is the default standard output. The match fluentd.test.** line tells fluentd to forward all messages matching the given pattern to the chosen standard output.
3. The third block is the MongoDB output. It requires the MongoDB plugin cited above to be installed, but we’ll talk about this later.

Let’s start the server and keep it running in foreground, to easily see incoming messages:

$ fluentd -c ~/.fluent/fluent.conf

Logging from bash to STDOUT

Now, let’s prepare a sample bash script to log things to fluentd. Open another terminal, create a bash script and paste the following content:

#!/bin/sh

fluent_log(){
  local project="$1"
  local script_name="$2"
  local message="$3"
  echo "{\""project\"":\""$project"\",\""script_name\"":\""$script_name"\",\""message\"":\""$message\""}" | fluent-cat fluentd.test.log
}

fluent_log "Library" "Reload books" "Started"

As you can see I created a wrapper function to make it easier to redirect logs to fluentd. Save the file, make it executable and run it. You should see output like this in your server:

2013-08-09 17:01:06 +0200 [trace]: plugin/in_forward.rb:150:initialize: accepted fluent socket object_id=70144024060720
2013-08-09 17:01:06 +0200 fluentd.test.log: {"project":"Library","script_name":"Reload books","message":"Started"}
2013-08-09 17:01:06 +0200 [trace]: plugin/in_forward.rb:191:on_close: closed fluent socket object_id=70144024060720

This is telling us that fluentd is accepting input from the fluent-cat command and it is redirecting it to standard output, according to the first rule.

Logging from bash to MongoDB

To go on in our test, we need to install MongoDB. Use the best way depending on your system (I used homebrew on my mac), run it and connect to its console via the mongo command.

Now, in the previous bash script, change the target of fluent-cat from fluentd.test.log to mongo.log. Save it, run it again, and type this in your MongoDB console:

$ db.test.find()

This time you should see an entry in the test collection:

{ "_id" : ObjectId("5204dfee9f60b167da000004"), "project" : "Library", "script_name" : "Reload books", "message" : "Started", "time" : ISODate("2013-08-09T12:26:22Z") }

Logging from ruby to MongoDB

Let’s see how to achieve the same result in a ruby script. Install the fluent-logger rubygem with

$ gem install fluent-logger

Then create a ruby script with the following content:

#!/usr/bin/env ruby

require 'rubygems'
require 'fluent-logger'

def fluent_log project, script_name, message
  Fluent::Logger::FluentLogger.open(nil, :host=>'localhost', :port=>24224)
  Fluent::Logger.post("mongo.log", {:project => project, :script_name => script_name, :message => message })
end

fluent_log "Library", "Update books", "Completed"

Run it, rerun the query in the MongoDB console, and a new entry should be present.

{ "_id" : ObjectId("5204dfee9f60b167da000005"), "project" : "Library", "script_name" : "Reload books", "message" : "Completed", "time" : ISODate("2013-08-09T12:46:32Z") }

Final considerations

The ease of use of fluentd allows to quickly setup a centralized log system in just a few hours. You could use any tool you want to browse data in the MongoDB database. You can make elaborate statistics, build charts, and do everything you want with it. According to the fluentd website, its simple architecture allows it to run with very good performances:

“Fluentd’s performance has been proven in the field: its largest user currently collects logs from 5000+ servers, 5 TB of daily data, handling 50,000 msgs/sec at peak time.”

So, I hope this post helped you to understand what this tool is about. I suggest you to check out the fluentd documentation to know more, it’s really complete and clear. If you found this post useful, feel free to drop me a line :)
